The desanders series made by NCB International are the perfect solution to meet any construction site need. Look at the features and choose the most adaptable type of desnader for your projects among the NCB 60E, NCB 120D and NCB 120E models.
Desanders
TECHNICAL DATA
| Model | type | NCB 60 E | NCB 120 D | NCB120 E |
|---|---|---|---|---|
| Efficiency | Km3/h | 60 | 120 | 120 |
| Installed Power | KW | 25 | 55 | 30 |
| Motor | KW | 11 Elettrico | 66.5 Diesel | 18.5 Elettrico |
| Pump | tipo | PEMO A/A 603 | WARMAN 4/3 C-AH PEMO K 125 | WARMAN 4/3 C-AH PEMO K 125 |
| Vibrators | tipo | OLI | OLI | OLI |
| Centrifuge Separator | mm | Ø280 | Ø390 | Ø390 |
| Main Screen | mm | 550x1600 OTP 4x20 | 650x1600 OTP 4x20 | 650x1600 OTP 4x20 |
| Vertical Dryer Screen | mm | 550x300 OTP 1 | 650x300 OTP 1 | 650x300 OTP 1 |
| Horizontal Dryer Screen | mm | 550x1200 OTP 0.7 | 650x1200 OTP 0.7 | 650x1200 OTP 0.7 |
| Dimensions | NCB 60 E | NCB 120 D | NCB120 E | |
|---|---|---|---|---|
| Height | mm | 2400 | 2500 | 2500 |
| Width | mm | 1200 | 1500 | 1500 |
| Total Length | mm | 3300 | 4400 | 4000 |
| Weight | Kg | 1600 | 2500 | 2200 |
